InVivoMAb anti-mouse CD86 (B7-2)

Catalog #BE0422

$164.00 - $4,280.00

Choose an Option...
  • 100 mg - $4,280.00
  • 50 mg - $3,024.00
  • 25 mg - $2,009.00
  • 5 mg - $600.00
  • 1 mg - $164.00
  • Custom Amount (Quotes Only)
In stock
Only %1 left

Product Details

The 2D10 monoclonal antibody reacts with mouse CD86 also known as B7-2. CD86 is an 80 kDa Ig superfamily member. CD86 is expressed by activated T and B cells, macrophages, and dendritic cells. This ligand binds to CD28 to provide a costimulatory signal necessary for T cell activation and survival, and cytokine production. Additionally, CD80 binds to CTLA-4 which inhibits T cells.


Isotype Rat IgG2b, κ
Recommended Isotype Control(s) InVivoMAb rat IgG2b isotype control, anti-keyhole limpet hemocyanin
Recommended Dilution Buffer InVivoPure pH 7.0 Dilution Buffer
Immunogen Mouse B cell lymphoma cell line 5C2
Reported Applications Immunoprecipitation
Flow cytometry
Functional assays
Formulation PBS, pH 7.0
Contains no stabilizers or preservatives
Endotoxin <2EU/mg (<0.002EU/μg)
Determined by LAL gel clotting assay
Purity >95%
Determined by SDS-PAGE
Sterility 0.2 µm filtration
Production Purified from cell culture supernatant in an animal-free facility
Purification Protein G
Molecular Weight 150 kDa
Storage The antibody solution should be stored at the stock concentration at 4°C. Do not freeze.
Immunoprecipitation, Flow Cytometry, Functional Assays
Chen C, Faherty DA, Gault A, Connaughton SE, Powers GD, Godfrey DI, Nabavi N. (1994). "Monoclonal antibody 2D10 recognizes a novel T cell costimulatory molecule on activated murine B lymphocytes" J Immunol 152(5):2105-14. PubMed

We have developed a panel of rat mAbs against dibutyryl cAMP-activated 5C2 cells. In this panel, one mAb, 1G10, recognized murine B7. Another mAb designated 2D10 did not bind to murine B7 but could recognize a surface molecule expressed only on dibutyryl cAMP-activated 5C2 mouse B lymphoma cells or on LPS-stimulated splenic B cells. This new molecule is referred to as early T cell costimulatory molecule-1 (ETC-1). From both activated 5C2 cells and splenic B cells, mAb 2D10 immunoprecipitated a 59- to 60-kDa protein, which was different from the 47- to 55-kDa murine B7 protein precipitated from the same cell populations. FACS analysis showed that, in contrast to B7, the expression of ETC-1 on 5C2 cells was induced by lower concentrations of dibutyryl cAMP and displayed a faster kinetics. LPS-stimulated splenic B cells expressed relatively low levels of B7 and much higher levels of ETC-1. Importantly, in an Ag presentation assay using activated 5C2 cells as APC, the secretion of IL-2 by C8A3 T hybrids was partially inhibited by mAb 2D10 alone and completely blocked by combination use of mAbs 2D10 and 1G10 in a dose-dependent and synergistic fashion. In a one-way primary MLR, mAb 2D10 alone at 0.1 to 1 microgram/ml inhibited T cell proliferation by 19 to 56%. However, an additive blocking effect (up to 76%) was observed when two mAbs were added in combination. Thus, our data have demonstrated that a novel T cell costimulatory molecule is present on activated murine B cells, which, in cooperation with B7, may play a critical role in optimal T cell activation.
