$178.00 - $4,651.50

$178.00 - $4.00

Choose an Option...
  • 100 mg - $4,651.50
  • 50 mg - $3,286.00
  • 25 mg - $2,183.00
  • 5 mg - $652.00
  • 1 mg - $178.00
  • Custom Amount (Quotes Only)
In stock
Only %1 left

Product Description

The CHK-152 monoclonal antibody reacts with the wings of the A domain on E2 protein of the chikungunya virus (CHIKV), an enveloped positive-strand RNA alphavirus from the Togaviridae family. The genome of alphaviruses encodes six structural proteins, namely capsid, E1, E2, E3, 6K, and TF, and four non-structural proteins (NSPs). The capsid enclosed RNA genome is surrounded by a lipid envelope containing heterodimers of E2 and E1 proteins. Upon infection, receptor binding induces clathrin-mediated endocytosis of virus, and the endosomal acidic pH triggers E1-mediated membrane fusion. The released nucleocapsid drives the replication of the viral genome and translation of viral proteins in the cytoplasm. Structural proteins are synthesized as a polyprotein, with the capsid released via autoproteolysis, and the E2/E1 proteins are transported through the secretory pathway to the plasma membrane for viral assembly, budding, and release. These viruses produce high titers of infectious particles both in vitro and in vivo. Mosquitoes are the vectors for CHIKV, and they spread the virus to humans, causing an acute infection with high viremia, fever, rash, and severe muscle and joint pain. Chronic symptoms, such as debilitating arthritis, may endure for several months. CHIKV outbreaks affect all major continents, and no approved vaccines or therapeutics further warrant therapeutic and vaccine development. Neutralizing antibodies such as CHK152 and CHK-166 serve as excellent tools for researchers, particularly in understanding the immune response to CHIKV and developing experimental therapeutics or vaccines.

Specifications

Isotype Mouse IgG2c, κ
Recommended Isotype Control(s) InVivoMAb mouse IgG2c isotype control, anti-dengue virus
Recommended Dilution Buffer InVivoPure pH 7.0 Dilution Buffer
Immunogen The La Reunion 2006 OPY-1 strain of CHIKV (CHIKV-LR)
Reported Applications in vivo neutralization of CHIKV E2
in vitro neutralization of CHIKV E2
Antibody-dependent cellular phagocytosis (ADCP)
Antibody-dependent neutrophil phagocytosis (ADNP)
Immunohistochemistry (frozen)
Immunofluorescence
Flow cytometry
ELISA
Formulation PBS, pH 7.0
Contains no stabilizers or preservatives
Endotoxin ≤1EU/mg (≤0.001EU/μg)
Determined by LAL assay
Purity ≥95%
Determined by SDS-PAGE
Sterility 0.2 µm filtration
Production Purified from cell culture supernatant in an animal-free facility
Purification Protein A
Molecular Weight 150 kDa
Storage The antibody solution should be stored at the stock concentration at 4°C. Do not freeze.
Need a Custom Formulation? See All Antibody Customization Options

Application References

  • in vivo neutralization of CHIKV E2
    Moore CM, Paul MJ, Pinneh E, Shanmugaraj B, Ashall J, Ramalingam S, Hewson R, Diamond MS, Fox JM, Ma JK (2025). "Characterisation of chikungunya virus neutralising monoclonal antibodies expressed in tobacco plants" J Biotechnol .

    Chikungunya virus (CHIKV) causes a debilitating musculoskeletal disease, characterised by flu-like symptoms, rash, and severe joint pain, which can last for months, even after the resolution of infection. Although the first CHIKV vaccine was approved in the USA in 2023 for use in adults, there is currently no specific antiviral therapy for infection. While neutralising antibody-based prophylactic and therapeutic agents have been considered, affordability and accessibility are major barriers to global regions where Chikungunya disease is epidemic. Here, we expressed five anti-CHIKV neutralising IgG monoclonal antibodies (mAbs) in N. benthamiana plants to investigate the potential use of this manufacturing platform. Plants produced IgG mAbs that compared favourably to mammalian cell-expressed antibodies, including for binding kinetics to CHIKV antigens and neutralisation activity. The yields of mAbs from plants were variable, as three of the antibodies' yields would need further expression optimisation to warrant future development. The successful expression of these antibodies in N. benthamiana plants supports the growing pipeline of Global Health product targets that could be developed using a highly transferable, low-cost, low-tech plant production platform in resource-poor countries.

  • in vitro neutralization of CHIKV E2 ELISA
    Stumpf MM, Brunetti T, Davenport BJ, McCarthy MK, Morrison TE (2024). "Deep mutationally scanned (DMS) CHIKV E3/E2 virus library maps viral amino acid preferences and predicts viral escape mutants of neutralizing CHIKV antibodies" bioRxiv .

    As outbreaks of chikungunya virus (CHIKV), a mosquito-borne alphavirus, continue to present public health challenges, additional research is needed to generate protective and safe vaccines and effective therapeutics. Prior research has established a role for antibodies in mediating protection against CHIKV infection, and the early appearance of CHIKV-specific IgG or IgG neutralizing antibodies protects against progression to chronic CHIKV disease in humans. However, the importance of epitope specificity for these protective antibodies and how skewed responses contribute to development of acute and chronic CHIKV-associated joint disease remains poorly understood. Here, we describe the deep mutational scanning of one of the dominant targets of neutralizing antibodies during CHIKV infection, the E3/E2 (also known as p62) glycoprotein complex, to simultaneously test thousands of p62 mutants against selective pressures of interest in a high throughput manner. Characterization of the virus library revealed achievement of high diversity while also selecting out non-functional virus variants. Furthermore, this study provides evidence that this virus library system can comprehensively map sites critical for the neutralization function of antibodies of both known and unknown p62 domain specificities.

  • Immunofluorescence
    Bardossy ES, Volpe S, Suzuki Y, Merwaiss F, Faraj S, Montes M, Saleh MC, Alvarez DE, Filomatori CV (2024). "Molecular basis of RNA recombination in the 3'UTR of chikungunya virus genome" Nucleic Acids Res 52(16):9727-9744.

    Chikungunya virus (CHIKV) is a rapidly spreading re-emergent virus transmitted from mosquitoes to humans. The emergence of epidemic variants has been associated with changes in the viral genome, such as the duplication of repeated sequences in the 3' untranslated region (UTR). Indeed, blocks of repeated sequences seemingly favor RNA recombination, providing the virus with a unique ability to continuously change the 3'UTR architecture during host switching. In this work, we provide experimental data on the molecular mechanism of RNA recombination and describe specific sequence and structural elements in the viral 3'UTR that favor template switching of the viral RNA-dependent RNA polymerase on the 3'UTR. Furthermore, we found that a 3'UTR deletion mutant that exhibits markedly delayed replication in mosquito cells and impaired transmission in vivo, recombines in reference laboratory strains of mosquitoes. Altogether, our data provide novel experimental evidence indicating that RNA recombination can act as a nucleic acid repair mechanism to add repeated sequences that are associated to high viral fitness in mosquito during chikungunya virus replication.

  • Flow Cytometry
    Raju S, Adams LJ, Earnest JT, Warfield K, Vang L, Crowe JE, Fremont DH, Diamond MS (2023). "A chikungunya virus-like particle vaccine induces broadly neutralizing and protective antibodies against alphaviruses in humans" Sci Transl Med 15(696):eade82

    Chikungunya virus (CHIKV) is a mosquito-transmitted alphavirus that causes epidemics of acute and chronic musculoskeletal disease. Here, we analyzed the human B cell response to a CHIKV-like particle-adjuvanted vaccine (PXVX0317) from samples obtained from a phase 2 clinical trial in humans (NCT03483961). Immunization with PXVX0317 induced high levels of neutralizing antibody in serum against CHIKV and circulating antigen-specific B cells up to 6 months after immunization. Monoclonal antibodies (mAbs) generated from peripheral blood B cells of three PXVX0317-vaccinated individuals on day 57 after immunization potently neutralized CHIKV infection, and a subset of these inhibited multiple related arthritogenic alphaviruses. Epitope mapping and cryo-electron microscopy defined two broadly neutralizing mAbs that uniquely bind to the apex of the B domain of the E2 glycoprotein. These results demonstrate the inhibitory breadth and activity of the human B cell response induced by the PXVX0317 vaccine against CHIKV and potentially other related alphaviruses.

Product FAQs
