Catalog #CPB510
Bispecific anti-mouse PD-1 x anti-mouse PD-L1 (LALA-PG) - PREORDER
Clone
Derived from clones RMP1-14 and 10F.9G2
Reactivities
Mouse
Isotype
mouse IgG2a (LALA-PG)-scFv, κ
Product Description
CPB510 is a 2+2 symmetric tetravalent bispecific engineered to simultaneously target mouse programmed cell death protein 1 (PD-1, CD279) and mouse vascular endothelial growth factor A (PD-L1, CD274, B7-H1) proteins. CPB510 contains the murine IgG2a constant region to reduce immunogenicity and the formation of anti-drug antibodies (ADAs) in mouse models and LALA-PG Fc-silencing mutations to abolish antibody-dependent cell-mediated cytotoxicity (ADCC) and complement-dependent cytotoxicity (CDC) while minimizing Fc-driven off-target toxicity and depletion of immune cells. This bispecific was designed to concurrently target and bind to the PD-1 receptor (typically found on activated T-cells) and the PD-L1 ligand (often expressed on tumor cells). Dual binding through bispecific engagement leads to blockade of the inhibitory PD-1/PD-L1 pathway, preventing immune suppression within the tumor microenvironment and enhancing activation and proliferation of antigen-specific T lymphocytes to promote tumor cell killing.
Specifications
| Isotype | mouse IgG2a (LALA-PG)-scFv, κ |
|---|---|
| Recommended Isotype Control(s) | Bispecific mouse IgG2a (LALA-PG)-scFv, kappa isotype control |
| Recommended Dilution Buffer | InVivoPure pH 7.0 Dilution Buffer |
| Mutations | LALA-PG |
| Reported Applications |
ELISA For information on in-vivo applications, please contact technicalservice@bioxcell.com |
| Formulation |
PBS, pH 7.0 Contains no stabilizers or preservatives |
| Endotoxin |
≤0.5EU/mg (≤0.0005EU/μg) Determined by LAL assay |
| Purity |
≥95% Determined by SDS-PAGE |
| Sterility | 0.2 µm filtration |
| Production | Purified from mammalian cell supernatant in an animal-free facility |
| Purification | Protein G |
| Molecular Weight | 200.1 kDa |
| Murine Pathogen Tests |
Ectromelia/Mousepox Virus: Negative Hantavirus: Negative K Virus: Negative Lactate Dehydrogenase-Elevating Virus: Negative Lymphocytic Choriomeningitis virus: Negative Mouse Adenovirus: Negative Mouse Cytomegalovirus: Negative Mouse Hepatitis Virus: Negative Mouse Minute Virus: Negative Mouse Norovirus: Negative Mouse Parvovirus: Negative Mouse Rotavirus: Negative Mycoplasma Pulmonis: Negative Pneumonia Virus of Mice: Negative Polyoma Virus: Negative Reovirus Screen: Negative Sendai Virus: Negative Theiler’s Murine Encephalomyelitis: Negative |
| Storage | The antibody solution should be stored at the stock concentration at 4°C. Do not freeze. |
| Need a Custom Formulation? | See All Antibody Customization Options |
